Annke 8CH 3K IP PoE Outdoor Surveillance Camera System
Annke 8CH 3K IP PoE Outdoor Surveillance Camera System
Couldn't load pickup availability
You gain complete control over your property with a complete eight-channel surveillance setup that delivers crisp 3K daytime footage and reliable night monitoring through integrated PoE connectivity.
- You monitor outdoor zones remotely via the Annke Vision mobile app, receiving targeted alerts when motion algorithms isolate human visitors and vehicles.
- You maximize recording time without extra drives, as the included NVR utilizes H.265+ compression to reduce storage consumption by up to seventy-five percent.
- You track precise movements around the clock with Smart Dual-Light cameras that switch between passive infrared and bright white lighting up to thirty meters away.
- You fend off harsh weather year-round, relying on weather-sealed units built to resist dust and moisture while operating within extreme temperature ranges.
IP Camera | ||
Camera |
Image Sensor |
1/3" Progressive Scan CMOS |
Max resolution |
3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
|
Main Stream |
50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) |
|
Substream |
50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 |
|
Video Bitrate |
32 Kbps - 8 Mbps |
|
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
|
Audio Input |
Built-in microphone, record with audio |
|
Audio Output |
Built-in Speaker, max. sound pressure level: 10 cm: 95 dB |
|
Lens |
2.8 mm |
|
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
|
Angle of View |
Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° |
|
Supplement Light Type |
Smart Dual-Light, IR, White Light |
|
Supplement Light Range |
IR: up to 30 m, wite Light: up to 30 m |
|
Motion Detection 2.0 |
Supoort, include Human & Vehicle detection |
|
Flashing Light Alarm |
High/Medium/Low Frequency/Normally On |
|
Audio Alarm |
Warning/Prompt |
|
Image Enhancement |
BLC, HLC, 3D DNR |
|
Wide Dynamic Range |
120 dB WDR |
|
Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
|
API |
Open Network Video Interface Version 19.12 |
|
Region of Interest (ROI) |
1 fixed region for main stream |
|
Privacy Mask |
4 programmable polygon privacy masks |
|
General Function |
Mirror,rotate,password protection, remote access |
|
Ethernet |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
General |
Housing |
Metal & Plastic |
Color |
White |
|
Storage |
Built-in microSD/SDHC/SDXC Slot, up to 512 GB |
|
Hardware Reset |
Yes |
|
Operating Power |
DC 12 V± 25%, max. 7.5 W; PoE (802.3af), max. 9 W |
|
Operating Temperature |
-22 °F – 140 °F/-30 °C – 60 °C |
|
Indoor/Outdoor Use |
Indoor/Outdoor |
|
Interface Protection |
IP67 |
|
Dimension (L X W X H) |
179 mm × 67.4 mm × 69.1 mm (7.1" × 2.7" × 2.7") |
|
Weight |
Approx. 315 g (0.7 lb.) |
|
NVR | ||
Video & Audio |
Video Compression |
H.265+/H.265/ H.264+/H.264 |
IP Video Input |
8CH POE |
|
Video Output |
HDMI & VGA Up to 1080P |
|
Incoming bandwidth |
60M |
|
Max Recording Resolution |
Up to 6MP |
|
Max Playback Resolution |
Up to 6MP |
|
Max Playback Channel |
8CH |
|
Max Playback Capacity |
4-ch@1080P, 1-ch@6MP@25fps |
|
Onvif Protocols |
Support |
|
Hard Drive |
HDD |
1 SATA interface |
HDD Capacity |
Up to 6TB capacity |
|
|
Network interface |
RJ45x1(10/100M) |
POE |
8 Ports(IEEE802.3af/at) |
|
USB |
2x USB 2.0 |
|
General |
Operating Power |
DC48V |
Power Consumption |
≤10W(without HDD and POE) |
|
POE: Max 25.5W for single port | ||
Working Temperature |
14 °F ~ 131 °F /-10 °C ~+55 °C |
|
Dimensions(W x H x D) |
10.4" × 8.9" × 1.9" / 265 × 225 × 48mm |
|
Weight (without hard disk) |
2.2lb / 1KG |
|
